Connect ASCII Devices to an Allen-Bradley PLC

The perfect tool to connect Legacy ASCII systems to an Allen-Bradley PLC

SKU: 460ETCA

460ETCA

Price$805.00$976.25

Clear

Product Description

Get Your ASCII Devices Connected Directly to the Data Table of Your Allen-Bradley PLC
The 460ETCA moves data between a serial ASCII device and 1 – 5 Allen-Bradley PLCs.

With the 460ETCA you now have a solution to get ASCII weather stations, UPS systems and any other ASCII devices that output a compound ASCII string connected to your Allen-Bradley PLCs. With the 460ETCA your ASCII devices are quickly and easily connected to user defined Tags or Registers in the data table of your Allen-Bradley PLC.

How Does the Data Move In and Out of the PLC?
Incoming and outgoing ASCII data is mapped to and from user defined tags or registers in the data table of your Allen-Bradley PLC. You allocate two areas of tags or register blocks in your Allen-Bradley PLC. One area is a user defined set of write only tags or register blocks accepting ASCII data. The other area is full of read only tags or register blocks to send data to your ASCII device. You directly map ASCII data into read and write locations in the data table of your Allen-Bradley PLC.

If your device uses delimiters, the 460ETCA can be configured to automatically remove the delimiters on incoming messages and add delimiters back in on outgoing messages. No need to deal with the delimiters in your PLC. If you need to parse your data, the 460ETCA can parse a string of ASCII data in up to 20 segments by delimiter or offset.

It’s designed to be a simple ASCII interface and it really is that simple.

Why Use Real Time Automation as a Gateway Supplier?
The 460ETCA provides an option to access those ASCII devices that always seem to creep into your architecture no matter how hard you try to keep them out. With the 460ETCA you can easily connect to those devices with your Allen-Bradley PLC.

When you call, a live person answers the phone. When you talk with sales, you will get honest answers and recommendations even if that means recommending someone else’s solution. When you get support, it is from an engineer who had a hand in the product’s development, and support doesn’t require a ticket or 24 hour wait. We are unashamed of the fact that we are a smaller company because that means you mean a lot more to us.

Try the RTA difference today and give us a call at 1-800-249-1612.



Real Time Automation ASCII to AB PLC SOLUTION COMPARISON
Part Number
460ETCA
Good ForBarcode Readers, Weigh Scales, Displays and other ASCII devicesWeather Stations, UPS Systems and any other Ethernet TCP/IP devices that output a compound ASCII string
PLC SetupASCII string gets mapped to a single Tag or RegisterASCII string can be parsed to multiple Tag or Register locations
AlarmingN/AEmail alarming available
Pricing
Same Pricing Model
  • Manual
  • 3’ power cable with Flying leads
  • 5 Year Hardware Warranty
  • IPSetup software — Automatically locates RTA Gateway on the network
  • Unlimited Firmware Feature Upgrades for Life
  • CAT5 Cross over cable for direct connection to PC during programming
  • Complete, Unlimited Access to our Industry Leading Support Staff

ASCII Device Features


Operation Modes
Bidirectional ASCII Transmit and Receive

Maximum Number of Devices Supported
2

Maximum Number of ASCII Characters Transferred
1024 in each direction

Delimiter Processing
Incoming delimiters automatically removed; Outgoing delimiters automatically added

Parsing
Parse string of ASCII data in up to 50 segments by delimiter or offset

Concatenation
Concatenate up to 50 segments/strings of ASCII data with optional delimiter

EtherNet/IP Tag Client Features

PLC Support ControlLogix, CompactLogix, FlexLogix, MicroLogix, SLC’s and PLC5E’s

Maximum Number of PLCs Supported 5

Maximum Number Read Tags or Registers Supported 150 per PLC

Maximum Number Write Tags or Registers Supported 150 per PLC

Array Support Yes, for all data types except strings

Supported Data Types ControlLogix / CompactLogix / FlexLogix: Bit, 32 Bit Array, SINT, INT, REAL, STRING, DINT, MicroLogix / SLC / PLC5E: 16 Bit Array, INT, REAL, STRING

Gateway Security

You can configure up to 9 different users access to diagnostic and configuration screens.

Alarming

Set <, <=, >=, >, ==, !=, and Change-of-State rules on any data moving through the gateway. If alarm rule is triggered an email notification can be sent.

Translation Table

Allows for data manipulation during protocol translation. Scaling and other data format changes can occur in the gateway.

Status and Counters

Protocol specific status, counters and error messages are accessible within the gateways diagnostics page. They can also be delivered to a connected device.

Diagnostic Logging Page

Allows users to see and log start up sequences, protocol specific messages & error messages.



460ETCA-N2EW
DATASHEET
460ETCA-N2E
DATASHEET  USERGUIDE
460ETCA-N34
DATASHEET  USERGUIDE
460ETCA-N700
DATASHEET  USERGUIDE
460ETCA-NNA1
DATASHEET  USERGUIDE
460ETCA-NNA4
DATASHEET  USERGUIDE
Click here to download our Gateway Comparison PDF
